WY-C5

Product Details

Description:

1.Ideal for using in the fields of lab, school, home applications and more.

2.Battery:1.5V AAx2pcs and 9V(NEDA1604) x1pcs(not included)

Features:

1.Mirrored Aluminum dial plate.

2.Overload and mis-used protection via two fuses, oxide varactordiodes.

3.Robust protective holster alongside.

4.20KΩ/ DC& 9 ,KΩ/V AC input sensitivity.

5.Adjustable back tilt device with hook-up designIdeal for using in the fields of lab, school, home applications andmore.

Specifications:

Model: WY-C5

Measuring Voltage Range:

0.1/2.5/10/50/250V+/-3.0%FSD, 1000V+/-4.0%FSD

AC Voltage:10/50/250V ±4.0%FSD ,1000V ±5.0%FSD

Measuring Current Range:

50u/2.5m/25m/250mA+/-3.0%FSD, 10A+/-4.0%FSD

Measuring Resistance Range:1 / 10 / 100 /1K / 10K

Measuring Capacitance Range:0.025-0.25-25uF(C2), 2000uF(C1)

DCV:0-0.1-2.5-10-50-250-1000V

ACV:0-10-50-250-1000V
