WY-E6

Features:

These affordable instruments combine a compact package with a strong feature set:

New smaller size fits easily into tight places

Precise measurements with 1.8% basic accuracy

Resolution up to 0.01A and 0.1 V

Measures AC current to 400 A

Measures AC volts to 600 V

Measures DC volts to 600 V (Fluke 322 only)

Resistance measurement to 400 Ω

Continuity for quick checking of shorts

Automatic low battery indicator

Display hold function

Two year warranty

oltage DC	Range: 0 - 400 V (Fluke 322 only)Resolution: 0.1 VRange: 0 - 600 V (Fluke 322 only)Resolution: 1 VAccuracy: 1% ± 5 counts
Voltage AC	Range: 0 - 400 VResolution: 0.1 VRange: 0 - 600 VResolution: 1 VAccuracy: 1.2% ± 5 counts (50 - 400 Hz)AC Response: Averaging
Current AC	Range: 0 - 400 AResolution: 0.1 ARange: 0 - 40 A (Fluke 322 only)Resolution: 0.01 AAccuracy: 1.8% ± 5 counts (50 - 60 Hz)Accuracy: 3.0% ± 5 counts (60 - 400 Hz)AC Response: Averaging
Resistance	Range: 0 - 400 ΩResolution: 0.1 ΩAccuracy: 1% ± 5 counts
Continuity	<= 30 Ω(beeps)

Environmental Specifications
Operating Temperature	-10°C to +50°C
Storage Temperature	-10 ºC to +50 ºC
Operating Altitude	2,000 meters
Temperature De-rating	Add 0.1 x specified accuracy for each ºC above 28ºC or below 18ºC

Safety Specifications
Safety Rating	600V CAT III

Mechanical & General Specifications
Size	190 x 63 x 35 mm
Weight	230 g
Warranty	One years
Battery Life	100 hours typical (2 AAA carbon zinc) (Not Included)
Jaw Opening	25 mm

Detailed Image:

Model No.:WY-E6
