WY-M22
Product Details
Description:
power measurements as well as for relative loss measurements in optical fibers. It features ingenious appearance, wide range of power measurement, high accuracy and user self-calibration function with high performance-to-price ratio.
Images:
Model No.: WY-M22
User self calibration function
Comfortable LCD display and optional backlight
LCD display supports night operation
Power measurements in dBm or mw and insertion loss in dB
Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries
Optional 10 minutes Auto-off function
Application
Maintenance in Telecom
Maintenance CATV
Test Lab of optical fibers
Other Fiber Optic Measurements
| Type | WY-M22 (3200A) | WY-M22 (3200B) |
| Wavelength(nm) | 800~1700nm | |
| Detector | InGaAs | |
| Measurement Range (dBm) | -70~+3 | -50~+26 |
| Uncertainty | ±0.25% | |
| Calibrated Wavelength(nm) | 850,980,1300,1310,1490,1550 1625 | |
| Resolution(dB) | Linear indication: 0.1% Loharithmic indication: 0.01dBm | |
| Optical Connector | FC/ Universal 2.5mm adaptor | |
| Power Supply | Alkaline Battery(3 AA 1.5V batteries) | |
| Battery Operating Time | 240 h with 1.5V Battery(3) | |
| Operating Temperature | -10 ~ +60 C | |
| Storage Temperature | -25 ~ +70 C | |
| Relative Humidity | 0 to 95% (non-condensing) | |
| Dimension(mm) | 172×82×33 | |
| Weight | 300g | |
