WY-M24
Product Details
Description:
*Analog TV analysis: Level, Tilt, C/N, Scan, and Trunk Voltage
* Digital TV analysis: Power Level, MER, and BER
* High-accuracy optical power meter offering 7 wavelengths and reference values
* 128x64 backlit LCD for various lighting conditions
* Long-lasting lithium battery provides over 4 hours of operation
* Upgrade software and edit channel plans via USB
This high-accuracy optical power meter offers 7 wavelengths and reference values. With its streamlined, lightweight design and user friendly interface, the C30 Plus offers the modern field technician optimum cost-performance for numerous applications.
Images:
Model No.: WY-M23
| Frequency | |
| Frequency Range | 5 MHz to 1000 MHz |
| Frequency Accuracy | ± 50 ppm (@ 20°C ±5°C) |
| Frequency Resolution | 10kHz |
| Channel Type | |
| Analog TV | NTSC |
| Digital TV | QAM 16/32/64/128/256 with constellation diagram plus QPSK and COFDM |
| FM Radio | Single frequency |
| Digital Channel | |
| Demodulation type | Standard ITU-T J.83 Annex A/B/C |
| Support | QAM 16/32/64/128/256 |
| Symbol rate | 1 MS/sec to 7 MS/sec |
| Bandwidth | 280 kHz to 10 MHz |
| MER (Modulation Error Ratio) | 39 dB (QAM) |
| Accuracy | ±2.0 dB |
| BER (Bit Error Rate) | 1E-3 to 1E-8 before and after R-S decoding (QAM) |
| Power measurement type | QAM, QPSK and COFDM |
| Digital Channel Average Power | |
| Level range | -30 dBmV to +60 dBmV |
| Constellation | |
| Accuracy | ±2.0 dB from 10°C to 30°C and ±3.0 dB from -10°C to 40°C |
| Resolution | 0.1 dB |
| Display mode | QAM 64 and QAM 256 with zoom in and zoom out capability |
| Analog Level Measurement | |
| Range | -35 dBmV to +60 dBmV |
| Accuracy | ±1.5 dB |
| Resolution | 0.1 dB |
| Input impedance | 75Ω (“F” type connector) |
| HUM Modulation | |
| Range | 2% to 5% |
| Channel Scan | |
| Number of Channels | 160 channels max |
| Scanning Speed | 5 channels per second |
| Scale | 1, 2, 5, 10 dB/div |
| Zoom | 1X, 2X, 3X, 4X, 5X five levels of magnification or full channel scan |
| Frequency Spectrum | |
| Bandwidth | 2.5MHz, 6.25 MHz, 12.5 MHz, 25 MHz, 62.5 MHz and full span |
| Scale | 1 dB, 2 dB, 5 dB and 10 dB/div |
| Tilt Measurement | |
| Number of Frequencies | maximum 12 with 0.1 dB of resolution |
| Limit Test Parameters | |
| Minimum/Maximum Video Level | 0 dBmV to + 30 dBmV |
| Minimum/Maximum Δ V/A | 10 dB to 20 dB |
| Minimum/Maximum Power Level | 10 dBmV to +30 dBmV |
| Minimum MER | 33 dB (varies with modulations and systems) |
| Max PRE/POST BER | 1.0 E-9 |
| General Specification | |
| Number of programs | Maximum 7 test parameters(Auto-Test) |
| Line Voltage Measurement Range | 0 V to 100 V (AC/DC) with accuracy of ±2 V |
| Storage Memory | 512K byte |
| Battery | 11.1V 1.6AH Lithium battery (5 hours of operation) |
| Charger | AC 100V to 240V 50-60Hz; charge time approximately 3 hours |
| Adaptor | RS 232C (With Serial to USB data cable included) |
| Dimensions | 218mm × 95mm × 49mm |
| Weight | 700g |
